Axminster Engineer Series - Page 10

Parts list ( 1 / MT3 ) --the spindle taper is MT3
No.
Drawing No.
Description
Q'ty
1-1
XN3A0201
spindle box
1
1-2
GB 818-85 - M4 x 6
cross recessed small pan head screw H type M4*6
4
1-3
X3C0219
spindle below oil seal ring I
1
1-4
X20206
B16 taper shank
1
1-5
GB/T 297-94 - 32907
cone roller bearing 32907
1
1-6
GB 6172-86 - M5
hexagon headed nut M5
2
1-7
XN3A0218
fine feeding handwheel
1
1-8
X3C0217
display fixed square screw
1
1-9
X3C0216
spindle sleeve below oil seal ring II
1
1-10
GB 818-85 - M3 x 8
cross recessed small pan head screw Z type M3*8
12
1-11
XN3A0215
base plate
1
1-12
GD300-165
the digital display module
1
1-13
XN3A0207
panel
1
1-14
X3C0210
up washer II
1
1-15
GB 819-85 - M5x35
cross recessed counter head screws M5*35
1
1-16
XN3A0210
bevel gear
1
1-17
XN3A0204
gear shaft
1
1-18
16-16
check ring 16
1
1-19
XN20243
clock spring
1
1-20
X3C0253
clock spring cover
1
1-21
XN3A0205
spindle box cover
1
1-22
X3C0208
bear seat
1
1-23
X3C0206
spindle timing belt
1
1-24
GB 70-85 - M4 x 35
hexagon socket head cap screw M4*35
4
1-25
X2021800
small handle assembly
1
1-26
XN3A0208
spindle sleeve locking shaft
1
1-27
XN3A0217
tighten the top rod
1
1-28
GB 79-85 - M6 x 14
slotted headless set screws M6*8
1
1-29
GB 77-85 - M6 x 8
inner six angle locking screws flat head M6*14
1
1-30
GB308-89 - 8
ball 8
3
1-31
XN3A0224
locking small shaft
1
1-32
X3C0238
worm locking handle
1
1-33
X3C0213
spindle sleeve
1
1-34
X3C0252
shaft gear left support flange
1
1-35
GB 77-85 - M6 x 10
inner six angle locking screw flat head M6*10
1
1-36
GB1096-79 4x10
parallet key 4*10
1
1-37
X3C0220
spindle up dust guard I
1
1-38
X3C0265
spindle up dust guard II
1
1-39
GB 70-85 - M4 x 10
hexagon socket head cap screw M4*10
3
1-40
XN3A0216
eccentric sleeve locking block
1
1-41
7_70 - 12 x 22 x 5
thrust ball bearing single 12*22*5
2
1-42
XN3A0209
worm shaft
1
1-43
XN3A0203
worm eccentric sleeve
1
