Axminster Engineer Series - Page 11

Parts list ( 1 / MT3 ) --the spindle taper is MT3
No.
Drawing No.
Description
Q'ty
1-44
X3C021100
locking bolt assembly
1
1-45
GB 119-86 - A 3 x 10
round pin A 3*10
1
1-46
GB 301-84 - 8106
thrust ball bearing 8106
1
1-47
GB 278-89 - 80106
deep groove ball bearing 80106
1
1-48
X3C0209
up washer
1
1-49
GB 810-76
slotted round nut
2
1-50
GB 70-85 - M4 x 12
hexagon socket head cap screw M4*12
6
1-51
GB 278-89 - 80107
deep groove ball bearing 80107
1
1-52
GB 893.1 - 62
check ring 62
1
1-53
GB 894.1 - 35
check ring 35
1
1-54
GB 70-85 - M5 x 16
hexagon socket head cap screw M5*16
4
1-55
X3C0212
spindle
1
1-56
HTD-M5 385
（
77T
）
timing belt Z77
1
1-57
GB 97.1-85 - 6
washer 6
4
1-58
GB 70-85 - M6 x 14
hexagon socket head cap screw M6*14
4
1-59
GB 879-86 - 3 x 8
spring round pin 3*8
1
1-60
X3C0237
assist small handle
1
1-61
GB 119-86 - A 3 x 14
round pin A 3*14
1
1-62
GB 819-85 - M3x10
cross recessed counter head screws H type M3*10
5
1-63
XN3A0220
washer
1
1-64
XN3A0213
spindle sleeve position shaft
1
1-65
20-20
check ring 20
2
1-66
XN3A0214
display fixed bracket
1
1-67
XN3A0222
round gear shaft adjust washer
1
1-68
GB 70-85 - M10 x 16
hexagon socket head cap screw M10*16
1
1-69
XN3A0202
bevel wedge
1
1-70
XN3A0223
wedge screw
2
1-71
XN3A0226
sleeve limted washer
1
1-72
GB 894.1 - 12
check ring 12
1
1-73
GB1096-79 4x18
parallet key 4*18
1
1-74
XN3A0211
atachment bracket
1
1-75
GB 5781-86 - M5x12
hexagon headed bolt M5*12
3
1-76
XN3B0203
motor support plate
1
1-77
XN3B0201
motor timing pulley
1
1-78
GB 896-86 3
spring washer 3
3
1-79
X3C023600
control handle assembly
3
1-80
XN3B0202
handle seat
1
1-81
XN3B0204
shaft gear right support flange
1
1-82
GF300220
conducting ring assembly
1
1-83
GB 70-85 - M5 x 12
hexagon socket head cap screw M5*12
4
1-84
motor
motor
1
1-85
C3C023500
F/R control pole assembly
3
1-86
GB2089-80 0.8x6x25
compress spring 0.8*6*25
3
10
