Axminster Engineer Series - Packing List

Parts list 5 (Note: some type without the protective guard assembly)
No.
Drawing No.
Description
Q'ty
5-1
GB 70-85 - M4 x 10
hexagon socket head cap screw M4*10
1
5-2
GB 70-85 - M4 x 12
hexagon socket head cap screw M4*12
3
5-3
XN3A2304
connect plate
1
5-4
X12304
block
1
5-5
the magnet block
1
5-6
X3C23C02
rotate shaft
1
5-7
ANSI B18.3.6M - M4x0.7 x 6
inner six angle locking screw-cone end metric M4*0.7*6
1
5-8 GB 96-85 - 6 washer 6 1
5-9
GB 889-86 - M6
hexagon locking nut M6
1
5-10
X3C23C0401
the inner shield
1
5-11
X3C23C03
outer protective cover
1
5-12
GB 819-85 - M4x10
cross recessed counter head screws M4*10
3
5-13
GB 97.1-85 - 5
washer 5
2
5-14 GB 835-88 - M5x20 knurled screws M5*20 2
5-15
X3C23C01
support plate
1
5-16
QKS7-5
safety limit switch
1
5-17
GB 818-85 - M4 x 25
cross recessed counter head screws M4*25
2
5-18
X3C23C05
spacer bush
1
5-19
X20003
dust guard
2
5-20
XN3A2302
rise and down guideway cover
1
Packing List
No. Name Description Q'ty Remarks
1 Bench Mill type: X2.7 or SX2.7 1 set
2
Fuse
110V/20A or 230V/10A
1 pce.
3
Manual
manual
1 pce.
4 Double end wrench
S1*S2: 8*10、14*17、17*19
each 1
5
L hex wrench
S: 3
、
4
、
5
、
6
、
8
each 1
6
U wrench assembly
X3C004
1 pce.
7
Oil cup
1 pce.
8 T nut X22001 2 pcs.
9
L hex wrench assembly
X3C2003
1
件
Below parts usually fixed on the machine (According to choice of MT3 or R8)
10* B16 drill chuck J2113/ 1-13mm / B16 1 pce.
MT3 type
11*
MT3 taper shank
X20206
1 pce.
12*
locking bolt assembly
X3C021100(X3C021101)
1 pce.
13*
slanting wedge
X3C2002
1 pce.
14*
JT6 drill chuck
3-16mm / JT6
1 pce.
R8 type
15*
R8 taper shank
X302A04(A)
1 pce.
16*
locking bolt assembly
X3C021101B
（
7/16")
1 pce.
