Copied from CE Certificate
The undersigned, Dip. Ing
Authorised by Laizhou Futian Machinery Co., Ltd.
Fenghuang Science and Technology Park,
Development Zone
Laizhou, Shandong 261400
P.R. China.
Model Number: PS315/230 (Dimension Saw)
Manufactured by Laizhou Futian Machinery Co., Ltd.
Is in compliance with the standards determined in the
following Council Directive.
EC Directive 2006/42/EC
Article 12, Section 3b
Warning
The symbols below advise that you follow
the correct safety procedures when using
this machine.
Fully read manual
and safety instructions
before use
Eye protection
should be worn
Ear protection
should be worn
HAZARD
Motor gets hot
Dust mask
should be worn
Two Man
Assembly
The Axminster Trade PS315 Panel Saw has been designed for the trade
workshop or keen home furniture maker. Upgraded over the previous model
with a high torque 2.2kW output mtor, a deeper section cast iron table, all
welded chassis and a cast iron rip fence holder. Constructed in cast iron with
welded heavy gauge steel and fitted with a 1,600mm alloy extrusion sliding
table, it is robust and stable for everyday use. The good sized, deep section
cast iron main table is fitted with a cast iron extension table giving a
combined surface of 825 x 800mm, plus a further steel plate extension giving
a total working surface of 1,265 x 800mm. A heavy gauge cast iron rip fence
holder and deep section alloy fence rail is included. The sliding table is smooth
running, fully adjustable and gives a travel of 1,300mm through the blade.
A cross-cut support table, with a telescopic support arm, can be positioned
anywhere on the sliding table and has a telescopic fence 1,200-2,200mm
long, enough for full size boards. This can easliy be removed without tools for
storage if required. A powerful 2.2kW output 1ph high torque motor drives
both the main blade and a scoring blade. The size of the main blade can be
a choice of 254, 305 or 315mm, without removing the scoring blade. The
scoring blade is easy to adjust through the table top and can be retracted
below the surface when not required. Smooth acting blade controls, efficient
dust extraction and a micro adjustable rip fence contribute to easy use.
Included as standard are a 315mm Axcaliber main blade, scoring blade, a rear
feed-off table, small mitre fence (of a clever design for use on the sliding table
with a work clamp), an edge shoe and table support legs. N.B. 16A supply
required.
Introduction
Index of Contents 02
Declaration of Conformity 02
What’s Included 03-04-05-06
General Instructions for 230V Machines 07
Specific Safety Precautions 07-08
Specification 08
Initial Assembly 08-09-10-11-12-13-14-15-16-17-18-19
Machine Footprint 19-20-21
Illustration and Parts Description 21-22-23-24-25-26
Positioning the Machine 27
Setting Up the Machine 28-29-30-31
Operating Instructions 32-33-34-35
Changing the Saw Blade 36-37
Routine Maintenance 38-39
Exploded Diagram/Parts List 40-41-42-43-44-45-46-47-48-49-50-51
Wiring Diagram 52
CE Certificate 53
Notes 54-55
