3
Quantity Item Model Number
1 No PS315 1600 Panel Saw (TRADE) PS315/230
Part Part
1 No Main Saw Assembly 0 1 No Right Hand Pressed Steel Table 11
1 No Sliding Table Extension Support Arm 1 1 No Rear Extension Table 12
1 No Rip Fence Control Assembly 2 1 No Sliding Table Extension Assembly 13
1 No Mitre Fence Assembly for (Sliding Table) 3 1 No Sliding Table Extension Support Bar 14
1 No Workpiece Support Shoe 4 1 No Operating Wheel Handles 15
1 No Push Stick 5 1 No Extraction Moulding Outlet 16
1 No Rear Table Support Bracket 6 1 No Crown Guard and Hose Assembly 17
1 No Fence Clamping Handle 1 No Sliding Table Assembly 19
Fence Assembly Clamping Handle 7 1 No Rip Fence Rail Shaft 20
1 No Right Hand Table Support Leg 8 1 No Rip Fence 21
1 No NVR Switch Emergency Stop Lever 9 1 No Workpiece Clamp Shaft 22
1 No Right Hand Cast Iron Table 10 1 No Sliding Table Fence Assembly 23
and distance stop
1 No Rip Fence Scale 24
Bags Comprising 18
1 No Hose Support Bracket B 1 No Locking Pin Knob for (Rise & Fall Wheel) F
1 No Blade Locking Bar C 1 No Sliding Table Locking Knob G
1 No L Handle 4mm Hex Key D 6 No Hex Keys 8-6-5-4mm H
1 No Spanner 17-13mm E 1 No Sliding Table Operating Handle I
6 No Scoring Blade Spacers J
1 No User Manual 2 No 100mm and 50mm Clips
Main Saw Assembly
Panel Saw Box Crates
