Axminster PS315 - Page 21

Sliding table extension
Support arm
Distance stop
assembly
Sliding table
extension
Workpiece
support shoe
Out feed roller
Telescopic extension
Emergency Stop
Rear extension table
Hose support bracket
Flexible hose
Right hand table
support leg
Push stick
45˚ degree operating handle
Rip fence scale
Blade
Machine Footprint
21
2,900mm
1 Metre extension
Illustration and Parts Description
