Axminster PS315 - Page 22

Illustration and Parts Description
22
Crown guard
Clamp assembly
Table locking knob
Extension table
support leg
Dust extraction outlet
Main table
Rear extension table
Extension table scale
Rip fence clamp
Work clamp
Sliding table
operating handle
Sliding table
mitre fence
Rise & full operating handle
Main saw assembly
Push stick
Sliding table
Rip fence
Rip fence assembly
Scale/Pointer
Rip fence clamp
Right hand cast
iron table
Right hand
extension table
Sliding table fence
Right hand
table support leg
Rip fence rail shaft
NVR switch/ Emergency stop
Riving knife
