Illustration and Parts Description
23
Distance stop assembly
Loosen the lift & shift handle
to reposition the stop
Sliding table mitre fence with overhead clamp (A),
Fence angle clamp (B), Overhead clamp (C)
For fine adjustment turn
the adjusting knob, (A)
Extension table 90˚ degree stop
Rip fence scale, (A)
Mitre fence scale (A),
Mitre fence stop (B)
A
BC
B
A
A
A
Rip fence control assembly guide bearings
