Scoring blade Hex screw access holes
• Height adjuster, (A)
• Left and right adjuster, (B)
Workpiece clamp shaft (22) with the work
clamp taken from the mitre fence assembly (3)
Motor and saw assembly
Saw blade tensioning
bolt for drive belt
Rip fence assembly: Clamping handle, (A)
Rip fence and Clamping handle, (B)
Main saw table, height adjusting
bolts, one to each corner beneath
the table
22
work clamp
Scoring blade drive belt
Saw tilt mechanism
Motor hold down bolts
Saw blade drive belt
A
B
Adjuster lock
A
B
