Diagram/List D
NO DESCRIPTION
D-1 Scale, cross cut table
D-2 Washer 6mm
D-3 Scale, cross cut table
D-4 Allen screw M6x12
D-5 Eccentric cam
D-6 Washer 8mm
D-7 Sunken head screw Mx10
D-8 "Z"lock plate
D-9 "Z" lock plate
D-10 Hex screw M8x20
D-11 Lock nut M6
D-12 Hex nut M6
D-13 End cap,cross cut table
D-14 Cross cut table
D-15 Roller
D-16 Hex screw M8x12
D-17 Bracket, rooler
D-18 Bracket, rooler
D-19 Base roller
D-20 Support rod, cross cut table
D-21 Joint, support
D-22 Thin hex nut M10
D-23 Bearing 8104
D-24 Swing arm, extension
D-25 Pan head screw Mx12
D-26 Insert, swing arm
D-27 Woolen sheet
D-28 Block
D-29 Roll
D-30 Bearing 6101
D-31 Spacer, roll
D-32 Pan head screw M5x6
D-33 Eccentric shaft
D-34 Swing arm
D-35 Hex screw M6x35
D-36 Stop collar
D-37 Bearing 6202
D-38 Shaft, swing arm
D-39 Hex screw M8x50
D-40 Thin nut M6
D-41 Support, swing arm
D-42 Hex screw M8x30
D-43 Hex screw M10x25
D-44 Sunk head screw M6x12
D-45 T-nut, extension fence
D-46 Lock table
D-47 T-block
D-48 Scale
D-49 End, extension fence
D-50 Carriage bolt M6x38
D-51 Screw guide
D-52 Flip stop base
D-53 Knurled knob
D-54 Spring, flip stop
D-55 Set screw
D-56 Spacer, ratchet lever
D-57 Ratchet lever, Flip stop
D-58 Allen screw M8x20
D-59 Stud, flip stop
D-60 Flip stop
D-61 Scale, extension fence
D-62 extension fence
D-63 Scale, cross cut fence
D-64 Taping screw ST4.2x12
D-65 End cap, cross cut fence
D-66 Lock stub, cross cut fence
D-67 Carriage bolt M8x70
D-68 T-block
D-69 Flat washer M8
D-70 Spacer, lock handle
D-71 Star-type lock handle
D-72 wing nut M8
D-73 Stub, cross cut table
D-74 T-block
D-75 Knurled knob, fence
D-76 End cap,swing arm
D-77 T-block,hold down
D-78 Washer 12mm
D-79 Stub, hold down
D-80 Eccentric shaft
D-81 Sleeve
