Do not start the saw with the workpiece touchinge the
blade.
FOR YOUR OWN SAFETY NEVER
OPERATE THE TABLE SAW WITHOUT
THE RIVING KNIFE IN PLACE!
Do not commence sawing until the blade has run up to
full speed. After switchinge off, never try to slow the saw
down more quickly by applying side pressure (with a
piece of wood?) to the blade. Apply the old joiner’s adage
of never getting hands within one handbreadth of the
blade. Leave the machine disconnected from the mains
supply until you are about to commence work.
Always disconnect the machine if you are leaving it
unattended.
Never leave the vicinity of the machine unless the blade
has come to a complete stop.
Do not attempt to carry out any maintenance, corrective
work, setting up etc., unless the machine is disconnected
from the mains supply. If any tools have been used
during setting up procedures, make sure they are
removed from the machine and stowed safely away.
Do not attempt to carry out cross cutting operations
‘freehand’, always use the mitre fence for small material
and the sliding carriage for larger workpieces. Unless you
are an experienced machine operator, do not attempt to
‘rip’ freehand, always use the guiding facility of the rip
fence. It is perfectly acceptable to support, guide, and
feed the timber with your hands whilst ripping stuff of
some length, however, as you approach the blade ensure
that the push stick is to hand, and that you use it.
Remember the emphasis of the ‘push’ should be between
the blade and the fence and close to the fence. Use your
free hand to support and guide the material on the
offside of the saw blade and at least 100mm away from
it. If the timber does not extend to at least 100mm to the
offside of the saw blade, the material possibly does not
need guiding or supporting.
Check (especially on site), that there are no foreign
objects e.g. old nails, screws, small stones etc embedded
in the material you are about to cut. If necessary take a
wire brush to the timber before working.
Code 101256
Model PS315
Rating Trade
Power 2.6kW (max input) 2.2kw output 230V 1ph
Blade Dia/Bore 254, 305 or 315mm x 30mm x 3mm
Blade Tilt 0-45°
Scoring Blade Diameter 90mm
Max Depth of Cut @ 45˚ 80mm (315)
Max Depth of Cut @ 90˚ 100mm (315)
Max Width of Cut with Fence 1,220mm
Table Size 385 x 800mm
Table Height 865mm
Sliding Table Size 1,600mm x 270mm
Dust Extraction Outlet 100mm
Min Extraction Airflow Required 1,000m³/hr
Overall L x W x H
1,600mm x 1,540mm(+740mm crosscut table) x 865mm
Weight 255kg
PLEASE NOTE: Some of this assembly
procedure is best accomplished by two
persons, some of the items are heavy and
awkward, and a mishandling error could
cause injury. Please think about what you are doing,
your capabilities and your personal safety.
Unpack all the boxes and check all the components
against the ‘What’s Included’ list. If any parts or
components are missing, please contact our customer
Main Saw
service department using the procedures and telephone
numbers listed in our catalogue, and you will be dealt
with quickly and efficiently.
PLEASE NOTE: The panel saw comes 80% assembled,
in order to reduce the footprint of the machine for
packaging, several items are dismounted from the
machine and need to be re-affixed.
please check all
the boxes, packets etc, to make sure that all the parts have
been accounted for.
Having unpacked the boxes, (please dispose of any
unwanted packaging responsibly), put the parts and
components where by they are readily to hand. Break
down the main box by knocking the sides away (be
careful of exposed nails etc.), but leave the machine
sitting on its pallet. Remove the protective grease film
that is coating all the unpainted parts of the machine.
Use a proprietary de-greasing agent. Unfortunately, this
cleaning process is always a bit ‘mucky’. You are advised
to wear overalls or coveralls etc., during the process.
After cleaning, lightly coat the exposed metal surfaces
with ‘anti rust’ oil spray to prevent any rusting.
1. Locate the crown guard and hose assembly (17),
and the dust extraction moulding (16). Remove the
four self tapping Phillips screws/washers from around
the machine cutout to the rear of saw frame. Insert the
