Axminster WORKSHOP AW150BDS - Assembly and Setup; Assembly Steps

ASSEMBLY
6
1
6
5
4
2
3
Loosen grub screw
Machined face
Machined hole
Remove the caphead
screws & washers
Mount the
linisher guard
assembly (E)
Slide the table (B) mounting bar into the machined hole
and tighten the grub screw using the supplied Hex key.
Using a square adjust the table until its perpendicular with
the sanding disc.
Reset the pointer to ‘ZERO’ by loosening clamping screw.
7
B
E
Clamping star knob
