DISASSEMBLE/REASSEMBLE THE CARTRIDGES
A) To disassemble, pull the cartridges apart from each other.
B) To assemble, rst align the attachment tabs.
C) Press the cartridges together.
LOAD THE CARTRIDGES
Never place your hands, ngers, or other body parts in front of the
cartridge. This is especially important when loading and unloading
the cartridge, as serious injury could result. When loading and
unloading always hold the cartridge on the sides.
Be sure to load the cartridges right side up. The top of the cartridge has
text on it.
A) Push the cartridges into the cartridge bay until you hear a “click.”
B) Then give the cartridges a slight tug to ensure they are
locked into place.
6
7
10
RECHARGE THE BATTERY
A) Shift the safety switch to the down (SAFE) position.
B) Conrm the CID is blank.
C) Press the 2 buttons on each side of the battery pack.
D) Pull the battery pack out of the CEW.
E) Press the battery pack into the dock. You should hear a click when
the battery pack is seated properly in the bay.
After the battery is fully recharged and all information is uploaded to
Axon Evidence (Evidence.com) services, the light on the dock next to the
battery pack will be solid green.
8
CONFIRM THE CEW RECOGNIZES
THE CARTRIDGES
After loading the CEW:
A) Point the CEW in a safe direction.
B) Shift the safety switch to the up
(ARMED) position.
C) Conrm the CID displays both cartridges.
D) Shift the safety to the down (SAFE) position.
UNLOAD THE CARTRIDGES
Point the CEW in a safe direction.
Be sure the safety is in the down
(SAFE) position. Do not put your
hands in front of the cartridges.
A) Press the cartridge release
button on top of the CEW.
B) Pull the cartridges up and
out of the CEW.
9
, Axon Evidence, TASER, and are trademarks of Axon Enterprise, Inc., some of which are registered in the US and other countries.
For more information visit axon.com/legal. All rights reserved. © 2020 Axon Enterprise, Inc.
MPC0274
REV D
