2 3
Thank you for purchasing this AXTON amplier!
To maximize the performance of this amplier and your complete car audio system installation,
we recommend you acquaint yourself thoroughly with all technical features and controlling
options of this AXTON amplier. Please read this manual carefully, before attempting the
installation.
If, after reading this manual, you still have questions regarding functions or the installation of
the amplier, we recommend that you consult your dealer.
SAFETY INSTRUCTIONS
n Do not turn on any function which may distract you while driving your vehicle.
Functions requiring sustained attention must only be used when the vehicle is at a
complete standstill. Make sure to always stop your vehicle in a safe place before
operating these functions. There are risks of causing an accident.
n Keep the volume at a low level to be able to hear exterior noises while driving
the vehicle. There are risks of causing an accident.
n Do not open the amplier or undertake any modication of the product. There
is a risk of accident, re or electric shock.
n Only use this amplier with 12V mobile applications. Any use other than for this
product intended are may lead to re, electric shock or injury.
n Use correct amperage fuses. There are risks of re or electrocution.
n Do not obstruct radiators and/or vents. Internal overheating may occur and cause
a re.
n Ensure all connections are properly made. Check the section of cable and the
type of cable if it does not correspond with the use. There is a risk of re, injury and/
or damage to the product.
n Do not use screw nuts or fasteners part of the steering or braking systems for
ground connection. The fasteners and nuts used for the brake and steering systems
(or any other security system) as well as various tanks must never be used for
grounding. Use of these parts as ground may deactivate the vehicle’s control system
and cause a re or other technical problem.
n Keep all small objects which could be swallowed, such as the fasteners and
screws, out of the reach of children. Swallowing such objects may cause serious
injuries. In the event of swallowing any of these objects, immediately seek medical
advice.
n Before starting the installation, disconnect the negative terminal of the battery
to avoid any risk of injury, re or damage to the equipment.
TECHNICAL SPECIFICATIONS
MONO AMPLIFIER A101
230 W x 1 @ 4 Ohm (< 1 % THD / 14.4 V)
380 W x 1 @ 2 Ohm (< 1 % THD / 14.4 V)
600 W x 1 @ 1 Ohm (< 1 % THD / 14.4 V)
Frequency response: 15 Hz – 250 Hz
Variable input sensitivity: 0.4 – 10 V
Signal to noise ratio: > 86 dB
Low pass lter: 50 – 250 Hz
Subsonic lter: 10 – 55 Hz
Dimensions LxWxH: 185 x 40 x 105 mm
2-CHANNEL AMPLIFIER A201
150 W x 2 @ 4 Ohms (< 1 % THD / 14.4 V)
260 W x 2 @ 2 Ohms (< 1 % THD / 14.4 V)
500 W x 1 @ 4 Ohms (< 1 % THD / 14.4 V)
Frequency response: 15 Hz – 35 kHz
Variable input sensitivity: 0.4 – 10 V
Signal to noise ratio: > 88 dB
High pass lter: 40 – 400 Hz
Low pass lter: 40 – 400 Hz
Dimensions LxWxH: 205 x 40 x 105 mm
4-CHANNEL AMPLIFIER A401
100 W x 4 @ 4 Ohm (< 1 % THD / 14.4 V)
170 W x 4 @ 2 Ohm (< 1 % THD / 14.4 V)
350 W x 2 @ 4 Ohm (< 1 % THD / 14.4 V)
Frequency response: 10 Hz – 35 kHz
Variable input sensitivity: 0.4 – 10 V
Signal to noise ratio: > 85 dB
High pass lter: 40 – 400 Hz
Low pass lter: 40 – 400 Hz
Dimensions LxWxH: 230 x 40 x 105 mm
6-CHANNEL AMPLIFIER A601
100 W x 6 @ 4 ohms (< 1 % THD / 14.4 V)
160 W x 6 @ 2 ohms (< 1 % THD / 14.4 V)
320 W x 3 @ 4 ohms (< 1 % THD / 14.4 V)
Frequency response: 10 Hz – 35 kHz
Variable input sensitivity: 0.4 – 10 V
Signal to noise ratio: > 85 dB
High pass lter: 40 – 400 Hz
Low pass lter: 40 – 400 Hz
Dimensions LxWxH: 282 x 40 x 105 mm
