Page #3 background imageLoading...
Page #3 background image
From the 16-pin harness:
Connect the Red wires to the ignition wire of the aftermarket radio.
Connect the Orange/White wire to the illumination wire of the aftermarket radio. If the
aftermarket radio has no illumination wire just tape off the Orange/White wire.
Connect the White wire to the left front positive speaker output of the aftermarket radio.
Connect the White/Black wire to the left front negative speaker output of the
aftermarket radio.
Connect the Gray wire to the right front positive speaker output of the aftermarket radio.
Connect the Gray/Black wire to the right front negative speaker output of the
aftermarket radio.
Connect the Green wire to the radio’s left rear positive speaker output.
Connect the Green/Black wire to the radio’s left rear negative speaker output.
Connect the Purple wire to the radio’s right rear positive speaker output.
Connect the Purple/Black wire to the radio’s right rear negative speaker output.
Connect the Blue/White wire to the radio’s amp turn on wire.
Connect the Brown wire to the mute wire of the aftermarket radio. If the aftermarket
radio does not have a Mute wire, tape up the Brown wire.
Connect the Light Green wire to the parking brake wire of the aftermarket
navigation radio.
Connect the Blue/Pink wire to the VSS or speed sense wire of the aftermarket
navigation radio.
Connect the Green/Purple wire to the reverse wire of the aftermarket navigation radio.
Plug the 16-pin harness into the GMOS-04.
3
Connections to be made
GMOS-04
