GMOS-LAN-03
®
3
Connections to be made
12-pin pre-wired ASWC-1 harness:
• This harness is to be used along with the optional ASWC-1 (not included) to
retain steering wheel audio controls. If the ASWC-1 is not being used, disregard
this harness. If it will be used, please refer to the ASWC-1 instructions for radio
connections and programming.
Note: Disregard the harness that comes with the ASWC-1.
• Connect the Red wire to the accessory wire.
• The following wire must be cut before programming the ASWC-1:
• For the following vehicles cut the Green/Orange wire. If your vehicle is not
listed, do not cut anything:
CHEVROLET
Cobalt 2007-2010
HHR 2006-2011
Malibu 2008-2012
PONTIAC
G5 2007-2009
G6 2010
G6 (5th digit of VIN must
be a J, K, or L) 2009
SATURN
Aura 2007-2009
Sky 2006-2009
Installing the GMOS-LAN-03
Initializing the GMOS-LAN-03
With the key in the off position:
• Connect the 16-pin harness with stripped leads, and the GMOS-LAN-03
harness, into the interface.
• Connect the GMOS-LAN-03 harness to the wiring harness in the vehicle.
• If using the ASWC-1, connect it after you initialize and test the GMOS-LAN-03,
with the key in the off position.
Attention! If the interface loses power for any reason, the following steps will need
to be performed again. Also, if installing an ASWC-1 connect it after you initialize
and test the interface/radio, with the key in the off position.
• Turn the key (or push-to-start button) to the ignition position and wait until the
radio comes on.
Note: If the radio does not come on within 60 seconds, turn the key to the
off position, disconnect the interface, check all connections, reconnect the
interface, and then try again.
• Turn the key to the off position, and then to the accessory position. Test all
functions of the installation for proper operation, before reassembling the dash.
