GMRC-04
2
Connections to be made
From the 10-pin harness:
• Connect the Red wire to the radio’s 12-volt accessory or switched
wire.
• When completed plug the 10-pin harness into the GMRC-04.
From the 32-pin harness:
•
Connect the Yellow wire to the radio’s 12-volt constant or memory wire
.
• Connect the Black wire to the radio’s ground wire.
• Connect the Blue wire to the radio’s antenna turn-on wire. If there is
no antenna turn-on wire is present, connect the Blue wire up to the
radio’s amplifier turn-on wire.
• Connect the Orange wire to the radio’s illumination wire. If your radio
does not have an illumination wire, just tape off wire.
•
Connect the White wire to the radio’s left front positive speaker output
.
• Connect the White/Black wire to the radio’s left front negative
speaker output.
• Connect the Green wire to the radio’s left rear positive speaker output.
• Connect the Green/Black wire to the radio’s left rear negative speaker
output.
•
Connect the Gray wire to the radio’s right front positive speaker output
.
• Connect the Gray/Black wire to the radio’s right front negative
speaker output.
• Connect the Purple wire to the right rear positive speaker output.
• Connect the Purple/Black wire to the radio’s right rear negative
speaker output.
