2- Remove the adhesive protector from templates A and B, and ca-
refully place them in the right place making sure they are perfectly
aligned and do not exceed the minimum and maximum spacing me-
asurements.
WARNING: It is very important to ensure that the minimum and maxi-
mum spacing between the 2 templates is 8 to 24 mm.
3- If the frame protrudes from the door leaf, use template B to mark
the housing into which the strike plate fits.
ALIGN
2
3
38
EN
