Technical Specifications
Basic functions:
- Led armature with 7 pixels that can be controlled separately
- Metal construction with protective grille for each pixel
- Standard U-shaped suspension bracket + mounting materials
- 2x quick coupler suspension brackets included
- 40W RGBW LED per pixel, with warm white
- 12 Built-in shows + 1 random show
- Various operating modes
- Adjustable dimmer curves
- Colour display with menu buttons
- Fan cooling
- Industrial design with unlimited applicational possibilities
- Power supply via lockable power connectors
Technical Specifications:
- Light source: 7x 40W Tianxin COB RGBW LED chip
- LED chips provided with a diffuser and reflector for wide beam angles
- 1.8” TFT LCD display
- Operating modes: automatic, sound-controlled, master/slave, DMX
- Dimmer curves: linear, halogen, S-curve, square, inverted square
- LED calibration correction option
- Power input: blue lockable power connector
- Power output: grey lockable power connector
- DMX input and output via 3-pin and 5-pin XLR
- DMX channel modes: 6, 9, 21, 30 channels
- Maximum power consumption: 278 watts
- Power supply: 100-240V AC, 50/60 Hz
- Fuse: F5AL250V 20mm glass
- Power factor: 1 at 110V, 1 at 220V
- Maximum housing surface temperature: 55°C
- To be used in environmental temperature: 0°C - 40°C
- Weight: 9.5 kg
- Dimensions: 492 x 464 x 147 mm
Projection:
- Beam angle: 109 degrees
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
