Ayra IntenZ CB700 - Device Overview and Guidelines; Component Identification; DMX Connection Ports

Overview and Operation Guidelines for this Device
1. Light output
2. Fan airflow cut-out
3. Quick-coupler mounting point
4. Suspension bracket attachment point
5. Fuse
6. Power input (lockable blue power connector)
7. Power output (lockable grey power connector)
8. Display (not visible in the picture)
9. Microphone
10. DMX input and output (3-pins XLR)
The information in this user manual is subject to change at any time without notice.
Version: 1.0 Date of creation and author's initials: 07-10-2019 RV Revision date and author's initials: -
