Ayre T-series User Manual

Screw driver Hand drill Ruler, knife Gas leak detector
& soup water
Thermometer Hex. wrench
(Large side: 4mm, 5mm)
Assembly,
disassmbly
Indoor installation
plate fixing
Ruler: Length &
distance
measurement.
Knife: Tape cutting
Leak inspection
Temperature
measurement at
Indoor suction
inlet/discharge outlet.
Service valve
operating
Core drill
(diameter 70mm)
Monkey spanner
(300mm): 2EA
Torque wrench Hook meter
(for current measurement)
Insulation
resistance meter
Flare tool set
Connnection cable Winter cover Anti-vibration
rubber
Band Adhesive Drain hose
Refrigerant pipe
(for high/low pressure)
Putty Vinyl tape Remote fixture Fixture clamping
screw
Remote
Refrigerant circuit
connection to
Indoor/Outdoor.
Chaging of wall-
through hole
Wire & pipe
finishing
Remote hanger Remote fixture
fixing
Indoor-Outdoor
wire connnection
Outdoor protection
in a unusedseason
like winter
Vibration absorption
of outdoor
Wire & pipe
finishing
Finishing Drainage
Wall through Indoor/Outdoor
pipe connection
Indoor/outdoor
pipe connection
Current, voltage,
resistance
measurement
Insulation resistance
measurement
(Electric shock prevention)
Pipe cutting,
Burr removal
Level
Clamp meter
Thermometer
Drive torch Mega tester
Remark: Some of the above parts are provided by the installer and not included in the standard air-conditioner.
1. Tools required
2. Accessories
Installation Instructions • T-series Split System Air Conditioner
Page 1
