Basic use
■ Basic model number structure
Model AVP 0
■ Positioner and Actuator Types
Positioner Type
Actuator Type
Model AVP300/301/302
(Integral Type)
Model AVP200/201/202
(Remote Type)
Single-acting linear diaphragm (Azbil
Corporation actuator model numbers:
PSA, HA, HK, VA, VR, RSA, GOM)
(See p. v.) (See p. xiii.)
Double-acting linear cylinder (Azbil
Corporation actuator model numbers:
VP, SLOP, DAP)
(See p. vii.) (See p. xvi.)
Single-acting rotary cylinder
(actuator for ball valves and butterfly
valves)
(See p. ix.) (See p. xix.)
Double-acting rotary cylinder
(actuator for ball valves and butterfly
valves)
(See p. xi.) (See p. xxi.)
0: Fixed
2: Remote type
3: Integral type
0: No transmission
1: With travel transmission (4 to 20mA DC or DE transmission)
2: HART
® protocol communication
