5-14
No. Name Part Number Quantity
Recommended
Replacement
Cycle*
1
(Years)
33 Product nameplate 80377079-001 1 —
34 Extension lever 80377142-001 1 —
35 Magnet unit assembly (EPM) 80377010-001 (direct)
80377010-002 (reverse)
1 —
36 Hex socket head cap bolt with spring washer (for EPM) 80377046-001 2 —
38 Reversing relay main unit (standard finish, air supply connection
RC1/4)
80377323-001 1 5
39 Reversing relay main unit (corrosion-resistant finish, air supply
connection RC1/4)
80377323-011 1 5
40 Reversing relay main unit (corrosion-resistant finish, air supply
connection RC1/4)
80377323-021 1 5
41 Reversing relay main unit (standard finish, air supply connection
1/4NPT)
80377323-002 1 5
42 Reversing relay main unit (corrosion-resistant finish, air supply
connection 1/4NPT)
80377323-012 1 5
43 Reversing relay main unit (corrosion-resistant finish, air supply
connection RC1/4)
80377323-022 1 5
44 Magnetic switch for external zero/span adjustment 80377080-001 1 —
45 Insect-proofing wire mesh for reversing relay 80377143-001 2 —
46 VTD assembly (angle sensor)*
4
80388590-001 1 —
47 O-ring (under terminal block)*
4
80020935-845 1 5
48 Sensor assembly
(Double bearing
position detector of
AVP200/201/202)
with M4 round
crimp terminals
Waterproof (Mounting screw M6)
Cable length 3 m
80388709-01100 1 —
TIIS Flameproof (Mounting screw M6)
Cable length 3 m
80388709-02100 1 —
Waterproof (Mounting screw 1/4-20UNC)
Cable length 3 m
80388709-03100 1 —
Waterproof (Mounting screw M6)
Cable length 5 m
80388709-01200 1 —
TIIS Flameproof (Mounting screw M6)
Cable length 5 m
80388709-02200 1 —
Waterproof (Mounting screw 1/4-20UNC)
Cable length 5 m
80388709-03200 1 —
Waterproof (Mounting screw M6)
Cable length 10 m
80388709-01300 1 —
TIIS Flameproof (Mounting screw M6)
Cable length 10 m
80388709-02300 1 —
Waterproof (Mounting screw 1/4-20UNC)
Cable length 10 m
80388709-03300 1 —
Waterproof (Mounting screw M6)
Cable length 20 m
80388709-01400 1 —
TIIS Flameproof (Mounting screw M6)
Cable length 20 m
80388709-02400 1 —
Waterproof (Mounting screw 1/4-20UNC)
Cable length 20 m
80388709-03400 1 —
*1. The recommended replacement cycle assumes standard conditions (JIS C 1804 and C 1805). A shorter cycle may be necessary depending on
environmental conditions (temperature, humidity, vibration, air quality, etc.) and operation profile (frequency of operation, ON/OFF opera-
tion, etc.).
*2. If travel transmission available
*3. If extension lever required
*4. Have an Azbil Corp. service representative perform replacement of the VTD assembly or O-ring (under the terminal block).
