Azbil AVP301 User Manual

Appendix A: Specifications
A-23
[Double-Acting, without Pressure Regulator] unit: mm
150
(220)
145
161
*2
Supply air connection
2B pipe
Auto/manual switch
Mounting bracket
U bolts and nuts
*3
41
41
±4° to ±20°
137 92 to 122
*4
270
Dedicated cable
Fasten properly in accordance
with electrical equipment
technical standards.
21
13870
98
*2 Output air connection (OUT1)
*1 Electrical wiring connection
*1 Electrical wiring
connection
72
46
83
7222
Explosion-proof
model
Ground
terminal screw
Ground
terminal screw
Terminal box terminal connection diagram
Terminal screw size: M4
Terminal connection diagram
Terminal screw size: M4
AVP200/202 AVP201
For rotary valve
*2 Output air connection (OUT2)
237
Main Unit Structure Electrical conduit Air pipe
Installation Screws
AVP Main Unit Position Detector
TIIS flameproof model, regular model G1/2 Rc1/4 M8 M6
Regular model 1/2NPT 1/4NPT 5/16-18UNC 1/4-20UNC
Notes *1 *2 *3 *4
