AB-7050
5
Specifications
Item Specification
Temperature 0 °C to 60 °C Measuring range
Humidity 0 %RH to 100 %RH (at 15 °C 35 °C)
RTD
(Pt100)
± 0.3 °C (at 0 °C to 60 °C)
* 1mA applied current, 0.15 m/s downflow
for Models TY7043Z0P0X(-1), TY7053Z0P00(-1), and HTY7043 series
Temperature
RTD
(Pt1000)
± 0.5 °C (at 0 °C to 60 °C)
* 0.1-0.3mA applied current, 0.15 m/s downflow
for Model TY7043Z0K00(-1)
Measuring accuracy
Humidity ± 3 %RH (within 30 %RH to 70 %RH range, at 25 °C), ± 5 %RH (within 20 %RH to 80 %RH
range, at 15 °C to 35 °C)
for Models HY7043 series and HTY7043 series
100 Ω / 0 °C (RTD (Pt100) conforming to JIS C 1604 Class A)
for Models TY7043Z0P0X(-1), TY7053 series, HTY7043 series
Temperature
1000 Ω/ 0 °C (RTD (Pt1000)equivalent to JIS C 1604 Class A)
for Model TY7043Z0K00(-1)
1 V DC to 5 V DC (linear to 0 %RH to 100 %RH)
* Min. 50 kΩ input impedance of the controller in connection
for Models HY7043T1000(-1), HTY7043T1P00(-1)
Output signal
Humidity
0 V DC to 10 V DC (linear to 0 %RH to 100 %RH)
* Min. 50 kΩ input impedance of the controller in connection
for Models HY7043T6000(-1), HTY7043T6P00(-1)
Max. 4.5 min. (at 0.15 m/s air velocity)
for Models TY7043 series and HTY7043 series (Neosensor)
Temperature
Max. 2.5 min. (reference value) (at 0.15 m/s air velocity)
for Model TY7053 series (Neosensor high sensitive type)
Time constant
(at 0.15 m/s wind
velocity)
Humidity Max. 40 sec. (at 0.15 m/s air velocity)
for Models HY7043 series and HTY7043 series (Neosensor)
Power supply 24 V AC +10/-15 % (50 Hz/60 Hz), 24 V DC ± 10 %
for Models HY7043 series, HTY7043 series
Power consumption 0.15 VA (24 V AC power), 100 mW (24 V DC power)
for Models HY7043TX000(-1), HTY7043TXP00(-1)
Insulation resistance Min. 500 V DC, 20 MΩ
Withstand voltage 500 V AC applied for 1 min. with max. of 1 mA leakage current
(between housing and terminals)
Environmental conditions
Rated operating condition Limit operating condition Transport/storage condition
Ambient temperature 0 °C to 60 °C -10 °C to 60 °C -20 °C to 70 °C For temperature
sensing
Ambient humidity 0 %RH to 100 %RH
(non-condensing)
0 %RH to 100 %RH
(non-condensing)
5 %RH to 95 %RH
(non-condensing)
Ambient temperature 15 °C to 35 °C -10 °C to 60 °C -20 °C to 70 °C For humidity
sensing
Ambient humidity 20 %RH to 80 %RH
(non-condensing)
0 %RH to 100 %RH
(non-condensing)
5 %RH to 95 %RH
(non-condensing)
Vibration 1.96 m/s
2
(10 Hz to 150 Hz) 1.96 m/s
2
(10 Hz to 150 Hz) 9.8 m/s
2
(10 Hz to 150 Hz)
Color Pale gray
Cover
PC resin
Materials
Base
Modified PPE resin
Weight Approx. 80 g
Installation With the mounting kit (sold separately).
Lead wire (0.75 mm
2
× 300 mm long) connection Connection
Modular connection only for Model TY7043Z0P01(-1)
* Modular jack is provided. LAN cable compliant with EIA/TIA-568 Category 3 or over
(⌀0.5 mm x 4 pairs) is required for modular connection.
Accessory Four main unit mounting screws (M3 x 16)
JIS: Japanese Industrial Standards
PPE: Polyphenylene ether
CE Marking Conformity
Models TY70X3Z0P0X, HY7043 series and HTY7043 series comply with the following Electromagnetic Compatibility (EMC).
EMC
: EN61326-1 Class B, Table 1 (For use in a basic electromagnetic environment)
(CISPR11: 2003, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11)
Note:
Models TY7043Z0K00 and TY7043Z0K00-1 (Pt1000 temperature sensor model of Neosensor) are "equipment which is inherently benign in
terms of electromagnetic compatibility" and "is excluded from the scope of the EMC Directive."
Guide for the EMC Directive 2004/108/EC (8th February 2010)
