AB-6600
CAUTION
Use this product under the operating
conditions (for temperature, humidity,
power, vibration, shock, mounting direction,
atmosphere, etc.) listed in the specications.
Failure to do so might cause fire or device
failure.
Installation and wiring must be performed
by qualied personnel in accordance with all
applicable safety standards.
All wiring must comply with applicable codes
and ordinances.
To connect the wires to the screw terminals,
use crimp terminal lugs that have insulation.
Failure to do so might cause short circuit and
result in device failure or re.
Firmly tighten the terminal screws.
Insufficient tightening of the terminal screws
might cause overheating or re.
Do not disassemble the product.
Doing so might cause electric shock or device
failure.
Dispose of the product as industrial waste in
accordance with your local regulations.
Do not reuse all or part of this product.
IMPORTANT
•
To use this product properly, follow the
instructions described in this manual and
the manuals for other devices connected
to this product.
•
Use the product within the rated operating
ranges given in this manual. Failure to do
so might cause contact welding and xed
output.
Dimensions
z
Insertion thermostat
Figure 1. Model TY6800Z, TTY6800Z (mm)
φ6.5
50
145
(152max.)
(φ80)
106.424.8
5.2
24.8
58.5 15.5
31
Grounding terminal
φ22 Knockout holes
(x2)
5.6
R
(71.5)
Temperature
sensor
Capillary length (exposed portion)
1350–1600 or 4750–5000
