10. Glass
The machine has a hardened smoked glass panel, (Venus grey) with a thickness of 4 mm. It has
a luminous transparency of 10%.
Changing a glass
With a Phillips screwdriver, remove the
transportation screws that are indicated with the
yellow arrows in the figure to the right and tilt
down the grid of channels in the door.
With a Phillips screwdriver, remove the screws of the front panel.
The front panel is held with three tabs and three slots in the door
