3.1.4. Regulation for the width and the height of the packet
To configure the channel to any format of packet of cigarettes use the deflectors. There are two
deflectors of different colours, they indicate what the format of the channel is:
White indicates a standard 80 mm channel,
but it can be used for selling short packets of
cigarettes.
Black indicates an «Extra-long» 100 mm
channel, but it can be used for selling standard
packets of cigarettes.
Depending on the height of the packet the regulation of the deflectors changes.
Move the wall of the channel along the length
of the bracket to fit it into the slot of the width
of the packet. Each step is 5 mm. The
regulation of the deflectors depends on the
thickness and the length of the packet.
