It has made a modification in the boards to improve the system to indicate the position of them
with a 2,54mm. molex connector It uses a jumper molex to indicate the position of the boards.
Reference. 03803490
To indicate the position of the buttons it
uses jumper molex.
1º Position
2º Position
3º Position
4º Position
