Azores Networks AX1500 User Manual

— 4 —
03 ONE ROUTER SETUP STEPS

The Azores Router can be connected according to the diagram above. Note the DSL/PON/Cable
Gateway must be connected to the Port 1 of Azores Router. When it is connected to the Internet ,the
LED light is steady green. If you can, try place the Azores Router in an open area like on a table or a
shelf.

Wired devices can be connected directly to ports 2, 3 or 4 for Internet access; Wireless devices can
use the network name (SSID) & password (see the sticker on the bottom of Azores Router) to
connect to Internet.

Azores Networks AX1500 Specifications

General

Brand	Azores Networks
Model	AX1500
Category	Network Router
Language	English
