Power
¤ Steady Red – reset button is pressed
¤ Steady Red – unit is booting up or unit failed to boot
¤ Green – firmware is loaded to the RAM / unit has successfully booted up
¤ Off – no power or PSU faulty
Ethernet LAN 1-4
¤ Blinking Green – indicates activity on the port
¤ Steady Green – Ethernet device is connected to he port
¤ Off – there is no Ethernet device plugged in to the port or the cable is faulty
44
Aztech FG7009GR(AC) Residential Gateway
