5
BUILDING A NEW MESH NETWORK
This requires a router to set a mesh system with your WMB250AC as your
Mesh Node. You would need an RJ45 or Ethernet cable (y
RJ45 provided on the package). You can follow the steps
mesh network.
A. Take out any one WMB250AC in the package (there may be two or
three devices in a package).
B. Power on and connect the device to any router via RJ45 or
Ethernet cable. This will become the master automatically.
C. Take out the rest of the device in the package and power on.
D. If you find that the MESH LED with master is solid white, it means
the mesh network has been established successfully.
E. You can access the Web GUI via new Master IP address to change
the default SSID and Password of your mesh network. The
Master
IP address can be found in your router’s GUI. Or you can do this by
“AztechMesh” App.
NOTE: At least two (2) WMB250AC units are needed for Mesh system to
work.
5
