12
6SHFL¿FDWLRQV
Configuration Active 15” Subwoofer and two 10” 2-way full-range speakers
Transducers:
Subwoofer
Celestion/15" TF-1530X
subwoofer with 3" voice coil.
Satellite Speakers
Celestion/B-52 COMP-4-CLB
Compression driver with PETP Film
Frequency Range 35Hz - 20kHz
Frequency Response 46Hz -18kHz
High Frequency Dispersion 90° x 40°
Maximum peak SPL 136dB
Power Output
LF: 400Wrms Class G
HF: 100Wrms Class AB+B
System Power 1200W
Input Impedance
20k Ohm Balanced
10k Ohm Unbalanced
Electronic Crossover
3rd order Butterworth @ 100 Hz
Controls
Right and Left Level Knobs
Sub Level Knob
Ground lift switch
Power switch
Phase Switch
115/230V switch
BBE ON/OFF
BBE HF Process, LF Contour
Indicators
Power
Protect
Limit
Signal
Cooling 2 SpeeD Fan
Amplifier Protection
Short circuit
Clip-limiter
Overheat mute
SOA output stage
Driver DC protection
Subsonic filter
Turn-on mute and soft ramp
Turn-on inrush current limiting
Celestion 10” speaker
with 2.5” voice coil
