8. Display
The display shows the current time. Press to the Move button
display the additional information:
Time:
12:45 Mo
05.Jun.2004
IP address:
IP: 192.168.
100.1
Mac address:
MAC: 00-05-64
00-0A-22
9. Setting the time
Hold down the Prg/Set button to change the display to
programming mode. The following appears:
Hour ?
12:45
The Move button can now be used to set the desired hour.
Press the Prg/Set button to confirm the set value and proceed
to the next input window.
Minute ?
12:45
Day ?
05.Jun.2004
Month ?
05.Jun.2004
Year ?
05.Jun.2004
Return ?
At the end of the input cycle, press Return to return to the
normal display. Programming can be exited at any time using
the ESC button.
Please note that when parameterising a time server via ETS,
the manual setting of the time is overwritten by an external
signal from the time server. As soon as a time server has been
configured in the ETS, it has priority.
10. Error indication in the display
The KNXnet/IP Interface Multicontrol includes an automatic
battery monitoring function. Every 24 hours, the battery is used
briefly in order to evaluate the service life and status of the
battery. If the voltage under this load falls below a limit value,
this is indicated both in the display and as an event on the
EIB/KNX bus.
Battery test not OK display via B
12:45 Mo B
05.Jun.2004
When this message is displayed the
battery should be replaced.
The KNXnet/IP Interface Multicontrol displays the load status
of the application for information. After an ETS download, all
application parameters that were set via the web configuration
tool are deleted. This status is indicated by an “E” (empty) in
the display.
12:45 Mo E
05.Jun.2004
11. Replacing the battery
The KNXnet/IP Interface Multicontrol has a 1/2 AA 3.6 V
lithium battery. Under normal operating conditions, the battery
has a service life of up to 2 years. However, if it does have
to be replaced, the battery cover can be opened by inserting
a screwdriver in the notches provided. Pull the battery out of
the battery compartment and insert a new battery. Ensure the
correct polarity.
MAN 6688 – 040411–1
