17
Step 6: A aching the brake cables
The front brake cables are the only cables that have not been fully pre-mounted.
These cables have been pre-mounted onto the steering stem (handlebars), but s ll
have to be a ached at the wheels.
1. First, guide a cable from the le brake lever on the handlebars via the guide
points on the le side of the steering tube and the underside of the front
frame (indicated with arrows in Figure 15) to the le front wheel. Insert the
inner cable (2) through the slot in the guide point (1) on the underside of
the front frame. Next, also guide the outer cable (3) through here (see detail
picture H).
