Babboe Curve - Step 8.1: Installing Cargo Box Seats

29
Step 8.1: Installing the cargo box seats
1. A ach the holder for the front seat to the bo om sec on of the front panel
with a long bolt and to the top sec on of the front panel with a short bolt (see
detail picture V).
Important! Adhere to the specifi ed order for nuts, bolts and washers in order
to secure everything in the best possible way (see detail picture V).
V.
32.
Parts needed:
- Holders for seats at the front and rear of cargo box (in Box II)
- 2x seats (iden cal) (Box III)
- Sachet L (3x M6 bolts (short), 1x M6 bolt (long), 4x M6 cap nuts,
4x M6 spring washers, 8x M6 washers)
Tools needed:
- Open-end spanner # 10
- Philips screwdriver
!
