8
Step 2: Moun ng the front wheels
1. Remove the two nuts/washers from the wheel axle. You will need these again
soon, so keep them at hand.
2. Gently place the front frame on its side.
3. Place the wheel into the front frame as shown in Figure 3. Make sure that
the protruding end of the brake lever/hub fi rst falls into the corresponding
a achment ring (see detail picture C).
Important! This a achment point is located in diff erent places on the two
wheels, so the braking mechanism is always situated to the le of the wheel
axle.
Parts needed:
- 2x front wheels (20-inch) (Box I)
Tools needed:
- Open-end spanner # 15
2.
C.
