Baby Tech LCD Baby Monitor User Manual

6
Product Overview
LCD MONITOR
1. Speaker
2. LCD Monitor Extendable Kickstand
3. TALK Button
4. CHANNEL Control Buttons
5. VOLUME Control Buttons
6. MENU Button
7. POWER/SLEEP
(DIM SCREEN)
Button
8. DC12V Power Input
9. AV-OUT
10. CODE Button
CAMERA
A. Light Sensor
B. Infrared LED’s
C. Power Indicator LED
D. DC5V Power input
E. Coding LED Indicator
F. POWER ON/OFF Button
G. Camera Antenna Connector
H. Camera Speaker Output
PULL & TWIST
PULL & TWIST
1
B
3
C
D
E
F G
H
6
7
8
9
10
2
A
4 5

Baby Tech LCD Baby Monitor Specifications

General

Brand	Baby Tech
Model	LCD Baby Monitor
Category	Monitor
Language	English
