BAC FXV-0806-12D Series User Manual

WWW.BALTIMOREAIRCOIL.COM
4
Fan Guard
Air Intake Louvers
BACross
®
Fill with Intergral
Drift Eliminators
Figure 1b. Dual Air Intake FXV3/CXVT
Coil Connection:
FXV3 Fluid In/
CXVT Refrigerant Out
Coil Connection:
FXV3 Fluid Out/
CXVT Refrigerant In
Spray Water
Distribution System
Access Door
Casing
Cold Water Basin
Removable Drift
Eliminators
BALTIDRIVE
®
Power Train
Prime Surface
Coil
Suction
Strainer
Spray Riser Pipe
Bleed Valve
Spray Pump
Access Door
Spray Pump
Motor
Make-up
Valve
Axial Fan(s)
Cold Water
Basin
Recirculating
Water Pump
Access Door
Figure 1. Single Side Air Intake FXV/CXVB
Coil Connection:
FXV Fluid In/
CXVB Refrigerant Out
Coil Connection:
FXV Fluid Out/
CXV Refrigerant In
BALTIDRIVE
®
Power Train
Spray Water
Distribution System
SunScreens
(Option Not Shown)
FXV, FXV3, CXVB, AND CXVT UNITS
Unit Operation and Storage
1
