SPECIFICATIONS
NDIR, Multi-Zone Sample Draw Systems
Refrigerants:
HGM300 Model CFC: R-11, R-12, R-113, R-114, R-502,
HFC: R-404a (HP62), R-407a, R-407c
(AC9000), R-134a, R-410a (AZ20),
R-507 (AZ50), R-508b (SUVA95)
HCFC: R-22, R-123, R-124, R-500, R-503,
R-401a (MP39), R-402a (HP80),
R-40b (HP81), R-408a, R-409a, R-23
HALON:1301
Measuring Range: 0 to 10,000 ppm
AGM300 Model Ammonia (NH
3
- also known as R-717)
Measuring Range: 25 to 10,000 ppm
Inputs: 4 point standard, expandable to 16 points in
4 point increments
Output Signal: 3 SPDT, 5 Amp, 240 VAC rated alarm relays
and 1 SPDT, 5 Amp, 240 VAC rated system
fault relay, plus a Digital Display w/ an optional
dual 4-20 mA DC analog output
Detector Type: Non-dispersive infrared
Sensitivity: All gases 1 ppm
HGM300 All gases ±10 ppm from 0 to 100 ppm,
Accuracy: ±10% of reading from 100 to 10,000 ppm
AGM300 ± 10 ppm from 25 to 100 ppm
Accuracy: ± 10% of reading from 100 to 10,000 ppm
Front Panel Display: Green LED indicates when unit is operating
properly, Red LED indicates when any monitored
point is above its alarm setting, Yellow LED
indicates a clogged sample line or other
system fault
Response Time: 5 to 120 seconds, depending on sample tube
length and gas concentration
Max. Monitoring Distance: Up to 500 feet from measuring point to
monitor
Power: 120 VAC, 60 Hz (Standard)
240 VAC, 50 Hz (Export)
240 VAC, 60 Hz (Domestic)
Size/Weight: 17" L x 12" W x 5.5" D / 15 lbs
(43.18cm L x 30.48cm W x 13.97cm D / 6.8 Kg)
SPECIFICATIONS REMOTE DISPLAY MODULES
RDM800 Model Compatible with HGM300 Model
ADM800 Model Compatible with AGM300 Model
Inputs: Accepts from one to four inputs via RS-485
from up to four HGM300 Refrigerant Monitors
Display: Backlit LCD displays the measured point in ppm
Trend Mode / Data logging: User may select a graphical display of the
ppm trend for any measured point
(100 data entries per point)
Output Signal Floating Ground: 2 SPDT, 5 Amp, 240 VAC assignable alarm relays
Alarm Indications: Channel display flashes, red light flashes,
alarm signal sent via RS-485
Input Fault Indication: Yellow light flashes and the LCD indicates
location of input fault
Max. Monitoring Distance: Maximum of 4,875 wiring feet from the
furthest HGM300 to the RDM800 Display
Power: 240VAC / 50/60 Hz, 120 VAC/60Hz
Size/Weight: 11" L x 10" W x 3" D / 5 lbs (wall mounted)
28cm x 25.4cm x 7.6cm/2.3Kg
ORDERING INFORMATION for Monitors
OPTIONS / ACCESSORIES
PART NO. DESCRIPTION
3015-4121 120VAC surge protector
3015-4122 230VAC surge protector
3015-4123 4-20 mA dc surge protector (two required)
3015-3133 Dual 4-20 mA dc output kit
3015-3069 External Visual alarm 120VAC
3015-3070 External Audible alarm 120VAC
3015-3076 External Audible / Visual alarm 120 VAC
3015-3423 Annual maintenance kit
3015-3235 Air sample tubing (250’per roll for standard refrigerants)
0304-2742 Air sample tubing (Ammonia only)
ORDERING INFORMATION for Remote Display Modules
3015-2875 RDM800 120VAC / 60 Hz
3015-2885 RDM800 240VAC / 50/60 Hz
3015-4195 ADM800 120VAC / 60 Hz
3015-4196 ADM800 240VAC / 50/60 Hz
Code A Model Number
HGM300 For use with CFC, HFC, HCFC and Halon Refrigerants
AGM300 For use with Ammonia Refrigerants
Code B Number of zones and connection type
-11 4 Zones with metal tube fittings
-12 8 Zones with metal tube fittings
-13 12 Zones with metal tube fittings
-14 16 Zones with metal tube fittings
Code C Input Power Type
-1 120VAC / 60 Hz (Standard)
-2 240VAC / 50 Hz (Export Applications Only)
-3 240VAC / 60 Hz (Domestic Applications Only)
System design supports compliance to the refrigerant monitoring
requirements of ANSI / BSR ASHRAE 15. Certified in compliance to UL
#3101-1, CE #EN613262, and EN61010-1.
