9. Plug connector on new fl exible probe assembly into printed
circuit board connector J3.
10. Replace printed circuit board, new fl exible probe assembly,
and rear case using the screws that were removed in Step
4.
11. Replace sensor.
12. Replace sensor-matching resistor.
13. Replace batteries and battery cover.
14. Test instrument response (refer to Section 4.2).
