Figure 7. Leakator 10 Part Locations (Sheet 2 of 2)

Leakator 10

Instruction 0019-9167

PROBE

CONNECTOR

SPEAKER

CONNECTOR

MATCHING

RESISTOR

(Located on

opposite side

of board)

EARPHONE

JACK
