SWING BEAM ASSEMBLY
STEP 7
BOLT WH 5/16x1 3/4
(2 PLCS)
NUT BARREL WH 5/16x7/8
(2 PLCS)
NUT BARREL WH
5/16x7/8
H100005
(3)
BOLT WH 5/16x1 3/4
H100011
(3)
I
N
S
E
R
T
27
