Backyard Discovery 1905016B - Page 36

LEFT SIDE GROUND BOARD ASSEMBLY
STEP 5
NUT BARREL
WH 5/16x7/8
(2)
WASHER
LOCK EXT
8x19
(2)
WASHER
LOCK EXT
12x19
(2)
BOLT WH
5/16x1/2
(2)
H1 - UNIVERSAL GROUND BOARD - W4L06276
1"x3 3/8"x42" (24x86x1066)
(2)
H1
H1
NUT BARREL WH 5/16x7/8
(2 PLCS)
WASHER LOCK EXT 12x19
(2 PLCS)
WASHER LOCK EXT 8x19
(2 PLCS)
BOLT WH 5/16x1/2
(2 PLCS)
36
