Backyard Discovery 2104617 - Roof Structure Construction

FRONT JOIST ASSEMBLY
FROM STEP 4
JOIST END - W4L14097
1 3/8"x5 1/4"x15" (36x134x381)
D1
(x1)
JOIST END - W4L14098
1 3/8"x5 1/4"x15" (36x134x381)
D2
(x1)
ˠ˨ˢ ʹɮ˧ʺ
ŗȕǻDNJNJrĵ˚ˠˠˀˡ˃
ˠ˨˨ ʹɮ˧ʺ
ɟǢËrNJ˚ˠˡɮˠ˨
ˠ˨˧ ʹɮ˧ʺ
ɟǢËrNJ˚˧ɮˠ˨
˨˥ˣ ʹɮ˧ʺ
Dŷĵǻ˚ˤ˚ˠˀˡ˃
˦˨ˡ ʹɮˡʺ
ĵµǢNNJrɟ˚ˢ˃
WASHER LOCK EXT BLK
12x19
(x8)
H100199
WASHER LOCK EXT BLK
8x19
(x8)
H100198
BOLT WH BLK
5/16x5-1/2
(x8)
H100964
NUT BARREL WH BLK
5/16x1-1/2
(x8)
H100193
LAG SCREW WH BLK
1/4x3
(x2)
H100792
NOTE LAP
ORIENTATION
FRONT JOIST
ASSEMBLY
Ǣǻrƻˤ
^ˡ ʹɮˠʺ
ğŷÝǢǻrŗ^
^ˠ ʹɮˠʺ
ğŷÝǢǻrŗ^
NOTE: TALLER POST ARE
LOCATED ON FRONT SIDE
OF THE ASSEMBLY.
WASHER LOCK EXT BLK
6x15
(x2)
H100405
ˣ˟ˤ ʹɮˡʺ
ɟǢËrNJ˚˥ɮˠˤ
