Backyard Discovery 2104617 - Page 20

RAIL - W4L14102
1"x4 1/2"x85" (24x112x2156)
Q2
(x1)
˦˨ˡ ʹɮˡʺ
ĵµǢNNJrɟ˚ˢ˃
ˠ˨ˡ ʹɮˣʺ
ŗȕǻDNJNJrĵ˚˦ˀ˧˃
ˠ˨˨ ʹɮˣʺ
ɟǢËrNJ˚ˠˡɮˠ˨
ˠ˨˧ ʹɮˣʺ
ɟǢËrNJ˚˧ɮˠ˨
ˣˤ˦ ʹɮˣʺ
Dŷĵǻ˚ˡ˃
ˣ˧˟ ʹɮ˧ʺ
Dŷĵǻ˚ˣˢˀˣ˃
ˠ˨˧ ʹɮ˧ʺ
ɟǢËrNJ˚˧ɮˠ˨
džˡ ʹɮˠʺ
NJÝĵ
ˠ˨˨ ʹɮ˧ʺ
ɟǢËrNJ˚ˠˡɮˠ˨
ˠ˨ˢ ʹɮ˧ʺ
ŗȕǻDNJNJrĵ˚ˠˠˀˡ˃
CORBEL - W4L14970
1 3/8"x4 3/8"x25 7/8" (36x112x657)
D5
(x2)
WASHER LOCK EXT BLK
8x19
(x12)
H100198
WASHER LOCK EXT BLK
12x19
(x12)
H100199
NUT BARREL WH BLK
5/16x1-1/2
(x8)
H100193
NUT BARREL WH BLK
5/16x7/8
(x4)
H100192
BOLT WH BLK
5/16x4 3/4
(x8)
H100480
BOLT WH BLK
5/16x2
(x4)
H100457
LAG SCREW WH BLK
1/4x3
(x2)
H100792
Ǣǻrƻ˥
WASHER LOCK EXT BLK
6x15
(x2)
H100405
ˣ˟ˤ ʹɮˡʺ
ɟǢËrNJ˚˥ɮˠˤ
20
