Backyard Discovery 2104617 - Page 21

RAIL - W4L14317
1 1/2"x3 1/2"x42 1/2" (36x86x1076)
E2
(x2)
rˡ ʹɮˡʺ
NJÝĵ
ˡˡˤ ʹɮˡˡʺ
ōrǻĵǻȕDr
ˣˤ˨ ʹɮ˧ʺ
Dŷĵǻ˚ˠˠˀˣ˃
L BRACKET 51x32x82x3.175
(x4)
A4M00855
METAL TUBE
(x22)
A4M01225
L BRACKET
(x2)
A4M01224
BOLT WH BLK
5/16x1 1/4
(x8)
H100459
NUT BARREL WH BLK
5/16x5/8
(x8)
H100469
ˡˡˢ ʹɮˡʺ
ĵDNJNħrǻ
˧ˤˤ ʹɮˣʺ
ĵDNJNħrǻˤˠɮˢˡɮ˧ˡɮˢʳˠ˦ˤ
L BRACKET
(x2)
A4M01223
ˣ˥˨ ʹɮ˧ʺ
ŗȕǻDNJNJrĵ˚ˤˀ˧
ˡˡˣ ʹɮˡʺ
ĵDNJNħrǻ
HOLES LOCATED IN THIS EDGE
DESIGNATE THE BOTTOM OF
THE RAIL
RAIL ASSEMBLIES
FROM ABOVE
NOTE LARGER L BRACKETS
FACE TOWARDS OUTSIDE.
PLACE RODS INTO BOTTOM
BOARD ON UPRIGHT. PLACE E2
ON TOP. SECURE RODS
BETWEEN BOTH BOARDS.
Ǣǻrƻ˦
21
