Backyard Discovery 2104617 - Page 28

ŗŷǻrʲ
SCREW TAPPING
1/4x3/4
(x14)
H100759
ROOF EDGE TRIM
(x4)
A4M01160
ROOF EDGE TRIM
(x2)
A4M01162
ˠ˥ˡ ʹɮˠʺ
NJŷŷ®r^µrǻNJÝō
ˠ˥˟ ʹɮˠʺ
NJŷŷ®r^µrǻNJÝō
ˠ˥˟ ʹɮˡʺ
NJŷŷ®r^µrǻNJÝō
FLUSH
˨˧ˢ ʹɮˡʺ
NJŷŷ®r^µrǻNJÝōǢƻĵÝNr
ˠ˥˟ ʹɮˠʺ
NJŷŷ®r^µrǻNJÝō
SLIDE ROOF EDGE TRIM 160 INTO EACH
SIDE OF EDGE TRIM SPLICE 983. PUSH
TOGETHER UNTIL ROOF EDGE TRIM 160
IS FLUSH WITH ROOF EDGE TRIM 162 ON
EACH SIDE OF THE UNIT. INSTALL SCREWS.
ROOF EDGE TRIM SPLICE
(x2)
A4M00983
SCREWS GO THROUGH EDGE TRIM INTO THE TOP
OF THE RIBS IN THE APPROXIMATE LOCATIONS SHOWN.
IT IS RECOMMENDED TO PREDRILL EDGE TRIM.
ŗŷǻrʲ
Ǣǻrƻˠˣ
ˠ˥ˡ ʹɮˠʺ
NJŷŷ®r^µrǻNJÝō
KEEP EDGE SCREWS IN
LINE WITH SCREWS ON TIN.
˦ˤ˨ ʹɮˠˣʺ
ǢNNJrɟ˚ˢˀˣ˃
SCREWS TO ATTACH TO
CENTER OF RAFTERS.
28
