Backyard Discovery 2104617 - Page 29

SCREW PWH BLK
8x3/4
(x8)
H100392
RAFTER BRACKET
(x4)
A4M01228
WASHER FLAT BLK
8x19
(x4)
H100630
NUT LOCK BLK
1/4
(x4)
H100653
BOLT WH BLK
1/4x2
(x4)
H100488
ˣ˧˧ ʹɮˣʺ
Dŷĵǻ˚ˡ˃
ˢ˨ˡ ʹɮ˧ʺ
ǢNNJrɟ˚ˢˀˣ˃
˥ˤˢ ʹɮˣʺ
ŗȕǻ˚ˠˀˣ˃
˥ˢ˟ ʹɮˣʺ
ɟǢËrNJ˚˧ɮˠ˨
ˡˡ˧ ʹɮˣʺ
NJ®ǻrNJDNJNħrǻ
REPEAT STEP TO FASTEN
RAFTER BRACKETS ON
FRONT OF UNIT.
Ǣǻrƻˠˤ
SLIDE ROOF PANEL
ON FROM BACKSIDE
CORBELS FROM PREVIOUS STEPS.
29
