Backyard Discovery 2104617 - Page 30

ŗŷǻrʲ
ŗŷǻrʲ
SCREW CONCRETE ANCHOR
1/4x2
(x16)
H100120
ˠˡ˟ ʹɮˠ˥ʺ
ǢNNJrɟ˚ˡ˃
˥ˢ˟ ʹɮˠ˥ʺ
ɟǢËrNJ˚˧ɮˠ˨
PRE-DRILL HOLES FOR CONCRETE ANCHORS
USNING A 3/16" CONCRETE DRILL BIT.
MANUFACTURER RECOMMENDS INSTALLATION ON
CONCRETE SURFACE OR CONCRETE POST PADS. SEE BELOW
FOR INSTALLATION ON WOOD DECK, YOU MUST ENSURE
THERE IS AMPLE STRUCTURAL SUPPORT UNDER DECK.
Ǣǻrƻˠ˥
WASHER FLAT BLK
8x19
(x16)
H100630
30
